Products Description
Z275 galvanized sheet refers to galvanized coils with a zinc layer of 150g/m2 and 275g/m2. Z275 represents the amount of zinc coating in grams per square meter. "Z275" means that both sides of the steel coil are coated with a zinc layer of 275g/m2.
Hot-dip galvanized steel sheet (roll) surface treatment
L Chromic acid passivation
Y Oiling
LY Chromic acid passivation plus oiling
GZ Skin finishing
Chemical Composition
|
Standard |
Grade |
C |
Si |
Mn |
P |
S |
Ti |
|
For cold forming Chinese standard |
DX51D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
DX52D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
|
DX53D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
|
DX54D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
|
DX56D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
|
DX57D+Z |
0.12 |
0.50 |
0.60 |
0.100 |
0.045 |
0.30 |
|
|
For cold forming Japanese standard |
SGCC |
0.15 |
0.50 |
0.80 |
0.050 |
0.030 |
0.025 |
|
SGCD1 |
0.12 |
0.50 |
0.60 |
0.040 |
0.030 |
0.025 |
|
|
SGCD3 |
0.08 |
0.50 |
0.45 |
0.030 |
0.030 |
0.025 |
|
|
SGCD4 |
0.06 |
0.50 |
0.45 |
0.030 |
0.030 |
0.025 |
|
|
For structures Japanese standards |
SGC340 |
0.25 |
0.50 |
1.70 |
0.200 |
0.035 |
0.025 |
|
SGC400 |
0.25 |
0.50 |
1.70 |
0.200 |
0.035 |
0.150 |
|
|
SGC490 |
0.30 |
0.50 |
2.00 |
0.200 |
0.035 |
0.025 |
|
|
SGC510 |
0.30 |
0.50 |
2.50 |
0.200 |
0.035 |
0.025 |
|
|
For structures AISI standards |
S220GD+Z |
0.20 |
0.60 |
0.70 |
0.100 |
0.045 |
0.025 |
|
S250GD+Z |
0.20 |
0.60 |
0.70 |
0.100 |
0.045 |
0.025 |
|
|
S280GD+Z |
0.20 |
0.60 |
0.70 |
0.100 |
0.045 |
0.025 |
Mechanical properties
|
Grade |
Yield Strength MPa≥ |
Tensile Strength MPa≥ |
Elongation A%≥ |
|
DX51D+Z/ZM/AZ/AM |
240-380 |
270-500 |
22 |
|
DX52D+Z/ZM/AZ/AM |
140-300 |
270-420 |
26 |
|
DX53D+Z/ZM/AZ/AM |
140-260 |
270-380 |
30 |
|
DX54D+Z/ZM/AZ/AM |
120-220 |
260-350 |
36 |
|
S220GD+Z/ZM/AM |
220 |
300 |
20 |
|
S250GD+Z/ZM/AZ/AM |
250 |
330 |
19 |
|
S280GD+Z/ZM/AM |
280 |
360 |
18 |
|
S300GD+AZ/AM |
300 |
380 |
18 |
|
S320GD+Z/ZM/AM |
320 |
390 |
17 |
|
S350GD+Z/ZM/AZ/AM |
350 |
420 |
16 |
|
S450GD+AZ/AM |
450 |
480 |
15 |
|
S550GD+Z/ZM/AZ/AM |
550 |
550 |
－ |
Import and export of galvanized coils
According to the latest statistics, the global import and export volume of galvanized coils has shown a steady growth in recent years. The main exporting countries include China, India, Japan, South Korea and Germany, while the main importing countries are the United States, Germany, France, Mexico and Canada.
As the world's largest exporter of galvanized coils, China's exports account for a considerable proportion of the global total. China's galvanized coils are mainly exported to the Asian, European and North American markets. India and Japan are also important exporters, and their products mainly flow to Asia and the Near East.
As the world's largest importer of galvanized coils, the United States' imports account for a considerable proportion of the global total. The United States mainly imports galvanized coils from Germany, France, Mexico and Canada to meet the needs of the domestic market. In addition, the European market is also an important import area for galvanized coils, with Germany and France being the main exporters of galvanized coils in Europe.
FAQ
Q:Can you send samples?
A:Of course, we can send samples to all parts of the world, our samples are free, but customers need to bear the courier costs.
Q:What product information do I need to provide?
A:You need to provide the level, specifications, and quantity you need to purchase.
Q:What are the shipping ports?
A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can choose other ports according to your needs.
Q:Does the product have quality inspection before loading?
A:Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed.
Q:How to pack the products?
A:Usually, our factory adopts standard export packaging or customizes according to the actual needs of customers
