High-quality aluminum-zinc coated steel
-
![Durable AZ150 Galvalume Steel Coil Supplier - Anti-Corrosive & High Temperature Resistance]()
Durable AZ150 Galvalume Steel Coil Supplier - Anti-Corros...Material: SGLCC / CS Type A Al-Zinc Coating: 150g/m² (55% Al, 43.4% Zn, 1.6% Si) Thickness: 0.13mm - 2.0mm Width: 700mm - 1250mmview more -
![Hot Dipped Galvalume Coil]()
Hot Dipped Galvalume CoilHot dipped Galvalume Coil is a highly corrosion-resistant material. It is made of cold-rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc, and 1.6% silicon. It is also...view more -
![AZ50 Galvalume Coil]()
AZ50 Galvalume CoilAZ50 Galvalume coil refers to a steel coil coated with aluminum-zinc alloy coating, where "AZ" stands for aluminum-zinc alloy, and "50" indicates the weight of the coating, specifically 50 grams...view more -
![AZ55 Galvalume Coil]()
AZ55 Galvalume CoilAZ55 Galvalume Coil is a highly corrosion resistant material. It is made of cold rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc and 1.6% silicon. It is also known as...view more -
![High Zinc Coating Aluminum Zinc Coil]()
High Zinc Coating Aluminum Zinc CoilHigh Zinc Coating Aluminum Zinc Coil is a highly corrosion-resistant material. It is made of cold-rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc, and 1.6% silicon....view more -
![Hot Dipped Galvalume Sheet]()
Hot Dipped Galvalume SheetHot Dipped Galvalume Sheet is a highly corrosion-resistant material. It is made of cold-rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc, and 1.6% silicon. Galvalume...view more -
![AZ50 Galvalume Sheet]()
AZ50 Galvalume SheetAZ50 Galvalume Sheet is composed of 55% aluminum, 43.4% zinc and 1.6% silicon solidified at a high temperature of 600℃. Its entire structure is composed of aluminum-iron-silicon-zinc, forming a...view more -
![AZ55 Galvalume Sheet]()
AZ55 Galvalume SheetAZ55 Galvalume Sheet is a zinc aluminum alloy coating. The resulting coating has excellent corrosion resistance and can be used in harsh environments.view more -
![AZ150 Galvalume Sheet]()
AZ150 Galvalume SheetAZ150 Galvalume Sheet is a highly corrosion-resistant material. It is made of cold-rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc, and 1.6% silicon. It is also known...view more -
![High Zinc Coating Aluminum Zinc Sheet]()
High Zinc Coating Aluminum Zinc SheetHigh Zinc Coating Aluminum Zinc Sheet is a highly corrosion resistant material. It is made from cold rolled steel and coated with a coating consisting of 55% aluminum, 43.3% zinc, and 1.6%...view more
Specifications of Galvalume Steel
|
Thickness |
0.12mm-6mm |
|
Width |
The conventional width below 0.5mm is 1000mm, 1200mm, and above is 1000, 1250mm |
|
Coil weight |
3-10 tons /customized |
|
Tolerance |
"+/-0.02 mm |
|
Substrate Type |
Hot rolled coil, Cold rolled coil |
|
Surface structure |
Zero spangles, Small spangles, Regular spangles, Big spangles |
|
Zinc layer thickness |
30g/㎡-275g/㎡ (Z275/G90) |
|
Standard |
AISI, ASTM, BS, GB, JIS |
|
Implementation standards |
GB/T2518 GB/T25052, EN10346, JIS G3302, ASTMA653 |
|
Certificates |
SGS, ISO 9001,CE |
Different forms of aluminum-zinc coated steel
01
Zero Spangle Galvalume Steel
Its smooth, flat surface makes it more suitable for modern styles or industrial equipment that pursue a simple and clean look.
02
Aluminum-zinc plated patterned sheet
Good anti-slip performance: The raised patterns (commonly lentil-shaped, diamond-shaped, round bean-shaped, etc.) increase the surface friction, effectively preventing slipping.
03
Galvalume Roofing Sheet
Metal roofing, in general, is known for its long lifespan, and the addition of Galvalume steel further extends this longevity. Galvalume-coated metal roofs can last for several decades, requiring minimal maintenance over the years.
04
Large Spangle Galvalume Steel
Its unique surface pattern is eye-catching and meets aesthetic needs, making it suitable for floral decorations, building exteriors, etc.
Galvalume Sheet
Aluminized zinc plate is a type of steel plate coated with an aluminum-zinc alloy, combining the physical protection of aluminum with the electrochemical protection of zinc, resulting in excellent corrosion resistance and heat resistance. It is mainly produced through a hot-dip galvanizing process. We mainly sell aluminum-zinc coated flat sheets and aluminum-zinc coated roofing sheets.
Applications of Galvalume Steel
Roofing
Galvalume steel is widely used in the roofing industry. Asphalt shingles can also be applied to the steel as a roof covering or on its own. This protects against hail and high winds in residential and commercial buildings. While added aesthetic appeal.
Siding
Galvalume steel is used behind sheet metal siding for both commercial and residential buildings. This then adds value by protecting the sides against any major form of corrosion. This is very popular as an option as it is more cost effective and works very well in those harsh climates.
Decking
This steel can is used widely within stairs and decks. This is so since, it is extremely durable and will not rust or corrode. Even if the area is a high people traffic area. It also provides a silent surface when walking or walking on the stairs. This can be important in a home with children, or for spaces that needs that reduced noise.
Handrails & Balustrades
Handrails & Balustrades can be made from galvalume steel. Of course the beauty is preserved without losing functionality. This is within the building’s specific need and any local building code requirements. Again if this area is a high traffic area, then you do not have to worry about corrosion because the protective coating is in place for the steel. If the building is in a high humidity area, then this steel is ideal.
Other Fixtures
For buildings that require mailboxes, the galvalume steel is the ideal choice. It will resist the harsher weather and if needed as a protective cover or enclosure for some windows or doors, would work quite well. The Galvalume steel is also great for those finer details of outdoor furniture and a fantastic choice if you are considering building a shed.
Galvalume Steel Packaging & Shipping
Heyan Steel has three types of steel packaging:
Simple kraft paper packaging
The first is simple kraft paper packaging, which is suitable for short-distance transportation and has a low cost;
Export-grade packaging
The second is standard kraft paper plus iron sheet packaging, which has a moderate cost;
Our Certificate
FAQ
We're professional galvalume steel manufacturers in China, specialized in providing high quality products with low price. We warmly welcome you to wholesale discount galvalume steel from our factory. For pricelist, contact us now.
