Products Description
Galvanized corrugated sheet is a metal material, usually made of galvanized steel sheet, with a corrugated surface texture. Galvanizing is an anti-corrosion treatment method that immerses steel materials in molten zinc liquid to form a uniform zinc layer to protect the steel from oxidation and corrosion.
Galvanized corrugated sheet is commonly used in the construction and industrial fields as a material for roofs, walls, partitions, etc. Its surface texture helps to increase the strength and stability of the material, and also increases the anti-slip properties of the surface, which is suitable for occasions where the environment is humid or anti-slip is required.
Product Specification
|
Thickness |
0.12-3.5mm |
|
Coating |
Z30-Z275 |
|
Hardness |
Mid Hard |
|
Standard |
GB,ASTM,JIS,DIN |
|
Certificate |
CE,SGS,ISO |
|
Processing Service |
Welding,Puching,Cutting,Bending |
|
MOQ |
1Ton |
|
Shape |
Sheet |
|
Zinc Coating |
30-275g/m2 |
|
Grade |
DX51d, DX53d, DX52d |
Mechanical properties
|
Grade |
Yield Strength MPa≥ |
Tensile Strength MPa≥ |
Elongation A%≥ |
|
DX51D+Z/ZM/AZ/AM |
240-380 |
270-500 |
22 |
|
DX52D+Z/ZM/AZ/AM |
140-300 |
270-420 |
26 |
|
DX53D+Z/ZM/AZ/AM |
140-260 |
270-380 |
30 |
|
DX54D+Z/ZM/AZ/AM |
120-220 |
260-350 |
36 |
|
S220GD+Z/ZM/AM |
220 |
300 |
20 |
|
S250GD+Z/ZM/AZ/AM |
250 |
330 |
19 |
|
S280GD+Z/ZM/AM |
280 |
360 |
18 |
|
S300GD+AZ/AM |
300 |
380 |
18 |
|
S320GD+Z/ZM/AM |
320 |
390 |
17 |
|
S350GD+Z/ZM/AZ/AM |
350 |
420 |
16 |
|
S450GD+AZ/AM |
450 |
480 |
15 |
|
S550GD+Z/ZM/AZ/AM |
550 |
550 |
－ |
|
Chinese Standards |
Japanese Standard |
European Standards |
|
DX51D+Z/DC51D+Z (CR) |
SGCC |
DX51D+Z |
|
DX52D+Z/DC52D+Z |
SGCD1 |
DX52D+Z |
|
DX53D+Z/DC53D+Z/DX54D+Z/DC54D+Z |
SGCD2/SGCD3 |
DX53D+Z/DX54D+Z |
|
S220/250/280/320/350/550GD+Z |
SGC340/400/440/490/570 |
S220/250/280/320/350GD+Z |
|
DX51D+Z/DD51D+Z (HR) |
SGHC |
DX51D+Z |
Application of galvanized steel tiles
Galvanized steel tiles are mainly used in the fields of construction and engineering, especially as roofing materials, and are also commonly used in walls, fences, carports, etc. In addition, galvanized steel tiles are also widely used in agricultural greenhouses, industrial plants, warehouses and other places.
Galvanized Corrugated Sheet surface treatment
L Chromic acid passivation
Y Oiling
LY Chromic acid passivation plus oiling
GZ Skin finishing
Advantages of Galvanized Corrugated Sheet
1. Excellent corrosion resistance;
2. Excellent mechanical properties
3. Easy to inspect and maintain;
4. Widely used
5. Relatively low cost.
Our factory
Currently, Heyan has 2 Tile pressing production lines, mainly producing products within the range of Z40-Z275g.Currently our daily output can reach 3,000 tons. At present, it has established cooperative relations with more than 50 countries. Our factory is located in Binzhou City with ISO/CE/SGS certifications.
Our product packaging
The Galvanized Corrugated Sheet packaging is all in the form of kraft paper + waterproof plastic film + galvanized iron sheet to ensure that the product is not damp and is delivered to customers in good condition.
Heyan's Services
Pre-sales: Create your exclusive customer profile within 30 minutes of receiving your inquiry.
Sales: Provide you with detailed plans and quotes within 24 hours.
After-sales: Update the production progress for you every day within 7 days.
24-hour online service is provided 365 days a year.
